3 Pieces Strand Post Tension Wedges 20CrMnTi 15.24mm 59 - 63 HRC

Large Image : 3 Pieces Strand Post Tension Wedges 20CrMnTi 15.24mm 59 - 63 HRC

Product Details:

Place of Origin:	China
Brand Name:	Fuhua
Certification:	ISO 9001
Model Number:	15.24

Payment & Shipping Terms:

Minimum Order Quantity:	negotiable
Price:	negotiable
Packaging Details:	standard packaging
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

3 Pieces Strand Post Tension Wedges 20CrMnTi 15.24mm 59 - 63 HRC

Description

Material:	20CrMnTi	Color:	Black
Model Number:	For 15.24mm	Efficecney:	＞95%
Capacity:	2000KN	Hardness:	HRC59-63
Highlight:	3 Pieces Post Tension Wedges , 20CrMnTi Post Tension Wedges , 63 HRC Strand Wedges

15.24mm 3 Pieces Strand Wedges For Post Tension System

Barrel raw material	40Cr
Wedge raw material	20CrMnTi;20CrMn5
Hardness of anchor(HRB)	25-35
Wedge Surface Hardness	HRA79-84
Wedge Core Hardness	HR38-46
Carburization Layer Depth	0.35-0.6mm/0.6-0.8mm
Anchor Efficiency Coefficient η a	η≥0.95
With-draw of wedge after stressing	≤6mm
Tempered	1-4
Retained Austenite	1-4
Inspection of Appearance	Tooth Shape without Defect,Bad Teeth,Variant
Standard	GB/T2301-2004
